Frequently asked questions

Our tile-over shower trays are made of a high density polyurethane composite.

All our trays are 60mm with the lips.  The technical drawings on our website show thickness of our standard sized trays after lip/s have been removed.

Thickness (after lips have been removed) is dependent on size of tray, outlet position and outlet type.

Size of tray and outlet position - the further the water needs to fall to reach the outlet the thicker the tray will be at the outside edges (due to our machined in fall to waste).

Type of outlet - channel and square tile-in insert trays require the tray to be thicker at the outlet point ( and therefore thicker at the outside edges).

We can custom make our tile-over trays any size up to 1150mm x 1950mm.

Yes, your outlet can be placed almost anywhere and will still have a fall.

Standard trays are supplied with a square chrome outlet/puddle flange kit and flashing to suit 3 sides of tray.

Channel trays are supplied with a drain tray, tile-in or patterned insert, PVC adapter, puddle flange and flashing to suit 3 sides of tray.

Square tile-in insert trays are supplied with a lowline tile-in waste/puddle flange kit and flashing to suit 3 sides of tray.
